Heavy Duty schakelaar rood slag- en trapvast 10A 35mm, off-on
€150.00 exclusief BTW
Additional information
| Switch Type | Pushbutton |
|---|---|
| Switch Operation | Momentary |
| Actuator Type | Dome Button |
| Actuator / Cap Color | Red |
| Case Color | Black |
| Contact Configuration | SPDT-NC-DB |
| Operating Force (Nom) | 7N / 25.2ozf |
| Contact Material | Fine Silver |
| Contact Voltage AC Nom | 250V |
| Contact Voltage DC Max | Not Applicable |
| Contact Current AC Max | 10A |
| Contact Current DC Max | Not Applicable |
| Illuminated | Non Illuminated |
| Illumination Color | Not Applicable |
| Illumination Voltage | Not Applicable |
| Switch Mounting | Threaded Bushing |
| Panel Cutout (H x W) | 22 x 20 |
| IP Rating | IP67 |
| Legend | Not Applicable |
| Operating Temperature Range | -40°C to +125°C |
| Standards Met | Not Applicable |
| Mechanical Life | 2000000 |
| Electrical Life | 100000 |
| Product Series | 76-94 |
Op voorraad
APPLICATIONS:
• Military environments
• Robust industrial
• Vandal resistant requirements
• Mining industry
• Petrochemical
• Process control
• Material handling
